CAM-8 Pro module

The CAM used on Head-end device with an operator authorized smart card gives access to Pay TV program

Description

Product Description

  • The CAM used on iDTV and STB with an operator authorized smart card gives access to Pay TV program (Consumer)
  • The CAM used on Head-end device with an operator authorized smart card gives access to Pay TV program multiple program descrambling supported (Professional)
  • CAS embedded officially certified product
  • Support MPEG-2/MPEG-4/SD/HD/3D
  • DVB-CI standard ISO/IEC EN50221
  • CI Plus specification v1.2 (CI Plus)
  • Widely compatibility tested with iDTV and STB models in the market

Features

  • Plug and Play
  • CA Chipset Pairing (Advanced Secure)
  • CA Menu and Message
  • Multi-Language
  • Parental Control
  • Application MMI MHEG-5 script using CI Plus Browser (CI Plus)
  • OTA software upgrade DVB SSU compliant

Processing

  • SMiT 32-bit Secure SoC
  • Flash Size:4M Bytes
  • RAM Size: 384K Bytes
  • 64 PID/Section filters (Professional)
  • Multi services descrambling up to 8 services descrambling (Professional)
  • TS process bandwidth: Up to 96Mbps
  • Common descrambling algorithm of DVB DVB-CSA1/2/3

Physical & Electrical Characteristics

  • Dimensions: PCMCIA Type II
  • Smartcard reader ISO7816 standard Class A and Class B
  • Operation voltage: 4.5V ~ 5.5V
  • Operation current: <150mA
  • Power consumption: < 750mW
  • CE RoHS REACH

Additional information

Brand

VERIMATRIX PRO
